5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling

5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling
5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling 5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling 5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling 5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling 5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling 5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling

Grande immagine :  5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling

Dettagli:
Luogo di origine: Hunan, Cina
Marca: SOLLROC
Termini di pagamento e spedizione:
Quantità di ordine minimo: 1
Prezzo: $200
Contatto

5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling

descrizione
Peso: 15 chilogrammi Materiale: Acciaio carburizzato
Tipo di elaborazione: trattamento termico e processo di lavorazione Filo: REG
Bit Dia.: 133 mm, 140 mm, 146 mm, 152 mm, 165 mm No. Fori per l'aria: 2
Buttoni di misura: 7×φ16, 7×φ18, 8×φ18, 8×φ18, 8×φ18 Buttoni anteriori: 6×φ14, 7×φ14, 7×φ14, 8×φ14, 8×φ16
Peso del pezzo: 15,5 KG, 16,0 KG, 16,5 KG, 17,0 KG, 19,0 KG Parte n.: SD5-130, SD5-140, SD5-146, SD5-152, SD5-165
Tipi di punte: Convesso, faccia piatta, concavo Inserisci tipi: balistico, semibalistico, a cupola
Dimensione del gambo: 5 1/4", 5 1/2", 5 3/4", 6", 6 1/2" Durezza della roccia: da morbido a medio, da duro a molto duro
Vita del tagliente: Lungo
Evidenziare:

5 Inch DTH Drill Bit

,

Carburized Steel Down the Hole Bit

,

High Performance SD5 Drill Bit

SD5 Down the Hole Drill Bits - 5 Inch DTH Bit for Mining
Product Overview
Our SD5 series Down the Hole drill bits are engineered for optimal performance in various mining applications. Available with three distinct bit head configurations - Convex, Flat Face, and Concave - each paired with specialized inserts to handle any rock formation challenge.
Optimal Bit Selection
Choosing the right drill bit depends on productivity and reliability requirements. For soft to medium rock formations with high penetration rates, ballistic and semi-ballistic inserts combined with flat face or concave bit heads deliver superior performance. For hard to very hard rock formations, domed inserts with convex heads provide extended drill bit life and durability.
Company Expertise
  • Over 10 years of specialized experience in manufacturing drilling tools and spare parts
  • Advanced manufacturing technology and equipment
  • Technical team with more than 13 years of professional expertise
Technical Specifications
DTH Bits Shank Bit Dia. (mm/inch) No. Air Holes Gauge Buttons Front Buttons Weight (Kg) Part No.
SD5 133 / 5 1/4" 2 7×φ16 6×φ14 15.5 SD5-130
SD5 140 / 5 1/2" 2 7×φ18 7×φ14 16.0 SD5-140
SD5 146 / 5 3/4" 2 8×φ18 7×φ14 16.5 SD5-146
SD5 152 / 6" 2 8×φ18 8×φ14 17.0 SD5-152
SD5 165 / 6 1/2" 2 8×φ18 8×φ16 19.0 SD5-165
Product Features
  • Ideal for water well drilling, micro piling, geothermal applications, and anchoring
  • Consistent and reliable performance in demanding conditions
  • Extended service life through durable construction
  • Easy maintenance and serviceability
  • Stable operation and precise drilling performance
Applications & Keywords
water well drilling geothermal drilling micro piling rock drilling ground drilling drilling tools DTH bits mining equipment
Product Images
5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling 0
Shipping & Packaging
Shipping Methods: By Air, By Sea, or By Express
Packaging: Ply-wooden cases + Pallet
5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling 1
5 Inch Carburized Steel High Performance DTH Drill Bit for Mining and Water Well Drilling 2
